CI858K01 ABB 工控控制系统

ABB CI858K01 3BSE018135R1 DriveBus 接口，CI858K01 DriveBus 接口套件包包括: CI858,通信接口。TP858,底板，宽度 = 60毫米，交号EXC3BSE018135R1。
型号: CI858K01
产品编号: 3BSE018135R1
DriveBus 协议用于与 ABB Drives 和 ABB Special /0 单元进行通信，DriveBus 通过 CI858 通信接口单元连接到控制器。DriveBus 接口用于 ABBDrives 和 AC 800M 控制器之间的通信。
DriveBus 通信专为 ABB 机区动系统 ABB 造纸机控制系统的分段动应用而设计。C1858 由处理器单元通过 CEX 总线供电，因此不需要任何额外的外部电源。
特点和好处
。 DriveBus 支持热插拔
。一C1858 最多可以连接 24 ABB 驱动器，一个 AC 800M 控制器最多可以连接两 CI858如果多 ABB 驱动器连接到 CI858，则需要个分支单元 NDBU，它可以构建具有物理星形拓扑的逻辑总线。分支单元可以被链接.包装包括:
– CI858，通信接口
-TP858，底板

CI858K01

ABB发明、制造了众多产品和技术，其中包括全球第一套三相输电系统、世界上第一台自冷式变压器、高压直流输电技术和第一台电动工业机器人，并率先将它们投入商业应用。ABB拥有广泛的产品线，包括全系列电力变压器和配电变压器，高、中、低压开关柜产品，交流和直流输配电系统，电力自动化系统，各种测量设备和传感器，实时控制和优化系统，机器人软硬件和仿真系统，高效节能的电机和传动系统，电力质量、转换和同步系统，保护电力系统安全的熔断和开关设备。这些产品已广泛应用于工业、商业、电力和公共事业中。

ABB集团位列全球500强企业（2008年在世界500强排列第256位，2009年位列第230位，2010年位列第237位），2009至2011年销售额都高达320亿美元。并在苏黎世、斯德哥尔摩和纽约证券交易所上市交易。

安全回路是保护负载或控制对象以及防止操作错误或控制失败而进行连锁控制的回路。在直接控制负载的同时，安全保护回路还给PLC输入信号，以便于PLC进行保护处理。安全回路一般考虑以下几个方面。

CI858K01

ABB CI858K01 3BSE018135R1 DriveBus interface, CI858K01 DriveBus interface package includes: CI858, communication interface. TP858, base plate, width = 60 mm, intersection number EXC3BSE018135R1.
Model: CI858K01
Product Number: 3BSE018135R1
The DriveBus protocol is used to communicate with ABB Drives and ABB Special /0 units, and DriveBus is connected to the controller via the CI858 communication interface unit. The DriveBus interface is used for communication between ABBDrives and the AC 800M controller.
DriveBus communication is specially designed for the segmented dynamic applications of ABB’s paper machine control systems. The C1858 is powered by the processor unit via the CEX bus, so no additional external power is required.
Features and benefits
. DriveBus supports hot swapping
. One C1858 can connect up to 24 ABB drives, one AC 800M controller can connect up to two CI858 If multiple ABB drives are connected to the CI858, a branch unit NDBU is required, which can build a logical bus with a physical star topology. Branch units can be linked. The package includes:
– CI858, communication port
-TP858, mainboard
ABB invented and manufactured many products and technologies, including the world’s first three-phase power transmission system, the world’s first self-cooling transformer, high-voltage direct current transmission technology and the first electric industrial robot, and pioneered their commercial application. ABB has a wide range of product lines, including a full range of power transformers and distribution transformers, high, medium and low voltage switchgear products, AC and DC transmission and distribution systems, power automation systems, various measuring equipment and sensors, real-time control and optimization systems, robotics hardware and software and simulation systems, energy-efficient motors and drive systems, power quality, conversion and synchronization systems, and other systems. Fusing and switching equipment to protect the safety of power systems. These products have been widely used in industry, commerce, power and public utilities.

ABB is one of the world’s top 500 companies (256th in 2008, 230th in 2009, 237th in 2010), with sales of $32 billion in 2009-2011. It is listed on the Zurich, Stockholm and New York Stock exchanges.

A safety loop is a loop of interlocking control that protects the load or control object and prevents operational errors or control failures. In the direct control of the load at the same time, the safety protection loop to the PLC input signal, in order to facilitate the PLC protection processing. Safety circuits generally consider the following aspects.

CI858K01
