140CPU67160C SCHNEIDER 施耐德通讯总线模块

SCHNEIDER  140CPU67160C  通讯总线模块

SCHNEIDER  140CPU67160C  通讯总线模块产品详情

制造业：在制造业中，该通讯总线模块可用于集成和控制各种自动化设备和系统，如机器人、生产线、传感器、执行器等。它可以与其他设备进行通信，实现数据传输和协调操作，提高生产效率和质量。

工业控制系统：通讯总线模块可与其他控制设备和仪表配合使用，实现对工业过程的监控和控制。它可以接收和发送数据，实现与PLC（可编程逻辑控制器）、DCS（分布式控制系统）等系统的通信，确保设备之间的协调运行。

140CPU67160C

能源管理：在能源管理领域，该通讯总线模块可用于集成能源监测和管理系统。它可以与能源计量仪表、电力监控设备等进行通信，实现能源数据的采集、分析和控制，帮助优化能源使用、提高能源效率。

楼宇自动化：通讯总线模块可以用于楼宇自动化系统，用于集成和控制建筑物的各种设备和系统，如照明、空调、安防、消防等。它可以与不同的楼宇设备进行通信，实现集中控制和监测，提高建筑物的运行效率和舒适度。
以太网固件

尽管以太网允许通过网络进行远程访问上传/下载过程，我们强烈建议安装在仅由CPU、电源和机架。一旦完成，使用仅包含IP的空程序配置PLC系统地址配置。请注意，以太网模块必须位于同一个逻辑以太网网络比带有操作系统加载程序的PC（用于两个IP地址、子网掩码和默认网关必须兼容）。

140CPU67160C

确保唯一连接到以太网的设备是PC运行OS加载器和CPU、NOE或CRP模块，CPU必须处于停止模式，NOE和CRP模块必须没有TCP流量。

运行操作系统加载程序的PC和CPU之间的物理连接或者可以执行以太网通信模块：

通过在PC和以太网通信模块

通过连接PC和CPU或以太网通信模块

通过集线器连接两根“非交叉”以太网电缆。

在这两种情况下，使用FTP协议，并且只有以太网协处理器可以通过这种方式更新CPU的固件。

应用

过程控制基础设施

安全

行业

Modicon Quantum自动化平台专门设计用于工业中的关键应用，如：

石化水泥

能源

冶金

隧道

水处理

机场

140CPU67160C

SCHNEIDER 140CPU67160C Communication bus module

SCHNEIDER 140CPU67160C Communication bus module Product details

Manufacturing: In the manufacturing industry, the communication bus module can be used to integrate and control various automation equipment and systems, such as robots, production lines, sensors, actuators, etc. It can communicate with other devices to achieve data transmission and coordinated operations, improving production efficiency and quality.

Industrial control system: The communication bus module can be used with other control equipment and instruments to realize the monitoring and control of industrial processes. It can receive and send data to achieve communication with PLC (Programmable logic controller), DCS (distributed control system) and other systems to ensure coordinated operation between devices.

Energy Management: In the field of energy management, the communication bus module can be used to integrate energy monitoring and management systems. It can communicate with energy metering meters, power monitoring equipment, etc., to achieve energy data collection, analysis and control, to help optimize energy use and improve energy efficiency.

Building automation: Communication bus modules can be used in building automation systems to integrate and control various equipment and systems in buildings, such as lighting, air conditioning, security, fire protection, etc. It can communicate with different building equipment, achieve centralized control and monitoring, and improve the operating efficiency and comfort of the building.
Ethernet firmware

Although Ethernet allows remote access to the upload/download process over the network, we strongly recommend installing only by the CPU, power supply, and rack. Once complete, configure the PLC system address configuration using an empty program that contains only IP. Note that the Ethernet module must be located on the same logical Ethernet network as the PC with the operating system loader (for both IP addresses, subnet masks, and default gateways must be compatible).

Ensure that the only device connected to Ethernet is the PC running the OS loader and the CPU, NOE or CRP modules, the CPU must be in stop mode and the NOE and CRP modules must be free of TCP traffic.

Physical connection between PC and CPU running the operating system loader or Ethernet communication module can be executed:

Communication modules via PC and Ethernet

By connecting PC and CPU or Ethernet communication module

Connect two “non-crossed” Ethernet cables through the hub.

In both cases, the FTP protocol is used, and only the Ethernet coprocessor can update the firmware of the CPU in this way.

Apply

Process control infrastructure

secure

profession

The Modicon Quantum automation platform is specifically designed for critical applications in industry, such as:

Petrochemical cement

Source of energy

metallurgy

tunnel

Water treatment

aerodrome
