469-P5-HI-A20-E GE 电机管理继电器

SR469-P5-HI-A20-E提供70-265伏交流电，90-300伏直流电控制电源。该设备有一个增强型前面板。但是，如果您需要一个可以在恶劣环境中使用的装置，请参考我们的SR469P5-HI-A20-E-H清单，除了一个额外的恶劣环境保形涂层外，它在各方面都与该装置相似
SR469-P5-HI-A20-E有一个精心设计的前面板，易于使用该面板包括一个RS-232程序端口接口，波特率为9600，可编程高达19200波特。这个面板有一个抽出式把手，可以密封，以防止任何未经授权的移动。前面板有一个大液晶显示器，可显示40个字符。用户可以通过该显示器在本地看到跳闸或报警等诊断信息。此外，面板还有电机和输出状态指示器、装置指示器、数字键盘、控制和编程键，包括复位、退出和菜单按钮，以及允许用户更改设定值的数值键

469-P5-HI-A20-E

469-P5-HI-A20-E GE 电机管理继电器
带5 A相位CT次级线圈的多线继电器，90-300VDC 70-265VAC，48至62Hz
469-P5-HI-A20-E GE 电机管理继电器
模拟输出 四(4)个4至20毫安模拟输出
控制权 90至300伏DC；48至62赫兹时70至265伏交流电
显示 增强型显示屏，更大的液晶屏
恶劣环境 钠
制造商 美国通用电气公司
相电流 5 A相CT次级线圈
469-P5-HI-A20-E GE 电机管理继电器
关于469-P5-HI-A20-E的常见问题
有哪些更常见的诊断信息可以帮助用户对469-P5-HI-A20-E继电器进行故障诊断，这些信息是如何显示的？
故障代码、跳闸、警报等。显示在469-P5-HI-A20-E屏幕上的信息总是按重要性顺序排列。用户可以使用下一个键来滚动消息并阅读多个显示的各种故障。如果469-P5-HI-A20-E在给定时间内没有显示故障代码或报警，信息LED指示灯将一直亮着。用户在使用469-P5-HI-A20-E时可能会遇到的一些更常见的警报有:拒绝输入密码、按下此处的键无效以及数据输入不完整。所有这些值都很容易确定。更多信息请参考Multilin 469系列说明书和安装手册。
469-P5-HI-A20-E CT的菜单导航难导航吗？在哪里可以找到有帮助的信息？
手册中的第1章:开始使用提供了469-P5-HI-A20-E的菜单导航参数的简单易用的细目分类。诸如电机和系统状态、计量数据和电机学习数据等菜单都可以选择，并允许用户更具体地查看出现在任何一个标题下的读数。这些分类很容易理解，也很方便用户使用。
AX Control有卖469-P5-HI-A20-E吗？有哪些购买选择？
469-P5-HI-A20-E是我们积极储备的产品，我们尽最大努力保持货架上的新品和翻新品。我们还为需要评估和维修的继电器有缺陷的客户提供统一报价维修选项。所有产品在购买或维修后返回时都提供保修。

469-P5-HI-A20-E

The SR469-P5-HI-A20-E provides 70-265 volts AC and 90-300 volts DC control power. The device has an enhanced front panel. However, if you need a unit that can be used in harsh environments, please refer to our SR469P5-HI-A20-E-H listing, which is similar to this unit in every respect except for an additional harsh environment conformal coating
The SR469-P5-HI-A20-E has a well-designed front panel for ease of use that includes an RS-232 program port interface with a baud rate of 9600 and programmable up to 19,200 baud. This panel has a pull-out handle that can be sealed to prevent any unauthorized movement. The front panel has a large LCD display that can display 40 characters. Users can see diagnostic information such as tripping or alarm locally through the display. In addition, the panel has motor and output status indicators, device indicators, numeric keypads, control and programming keys, including reset, exit and menu buttons, and numeric keys that allow the user to change set values
469-P5-HI-A20-E GE Motor management relay
Multiwire relay with 5 A phase CT secondary coil, 90-300VDC 70-265VAC, 48 to 62Hz
469-P5-HI-A20-E GE Motor management relay
Analog output Four (4) analog outputs from 4 to 20 mA
Control 90 to 300 volts DC; 70 to 265 volts AC at 48 to 62 Hz
Display enhanced display, larger LCD screen
Harsh sodium
Manufacturer General Electric
Phase current 5 A phase CT secondary coil
469-P5-HI-A20-E GE Motor management relay
Frequently Asked Questions about 469-P5-HI-A20-E
What are some of the more common diagnostic information that can help a user fault diagnose the 469-P5-HI-A20-E relay, and how is this information displayed?
Fault codes, trips, alarms, etc. The information displayed on the 469-P5-HI-A20-E screen is always in order of importance. The user can use the next key to scroll through messages and read the various faults on multiple displays. If the 469-P5-HI-A20-E does not display a fault code or alarm within a given time, the information LED will remain on. Some of the more common alarms that users may experience when using 469-P5-HI-A20-E are: Password denied, invalid keys pressed here, and incomplete data entry. All of these values are easy to determine. Refer to the Multilin 469 Series manual and installation manual for more information.
469-P5-HI-A20-E Is the menu navigation for CT difficult to navigate? Where can I find helpful information?
The manual in Chapter 1: Getting Started provides an easy-to-use breakdown of the menu navigation parameters of 469-P5-HI-A20-E. Menus such as motor and system status, metering data, and motor learning data are selectable and allow the user to view the readings that appear under any one heading more specifically. These categories are easy to understand and easy for users to use.
Does AX Control carry 469-P5-HI-A20-E? What are the buying options?
469-P5-HI-A20-E is a product that we actively stock and we do our best to keep new and restocked on the shelves. We also offer a flat quote repair option for customers who need to evaluate and repair defective relays. All products are covered by warranty upon return after purchase or repair.
