1756-L73  A-B罗克韦尔 处理器模块

1756-L73  A-B罗克韦尔 处理器模块能够连接128，000个输入和输出信号以及4000个模拟输入和输出信号。它可以实现本地I/0配置，其中I/0模块安装在安装控制器的同一机箱内，或者实现分布式1/0拓扑，其中扩展1/0安装在远离处理器的位置，并通过扩展通信总线提供1/0.该控制器支持以太网I/P、DeviceNet、 ControlNet、Synchlink以及传统通信协议，如Data Highway Plus (DH+)、Remote l/0RI0)和第三方协议，它也可以被配置成与网关和协议转换器通信。同样，该控制器与何Allen-Bradley encompose partnercontrollogix模块兼容。
1756-L73  A-B罗克韦尔 处理器模块该控制器还带有集成运动，因为它支持SERCOS接口、模拟运动传感器和以大网I/P上的运动控制。在对该控制器进行编程时，适用的编程语言包括继电器梯形图、结构化文本、功能框图和顺序功能图。

1756-L73

该控制器能够处理32个控制器任务，每个任务100个程序，而事件任务接受所有事件触发。该控制器配有8MB用户内存和0.98MB的I/O内存。它还配备了能量存储技术，无需使用电池来保存易失性存储器中的内容。
1756-L73  A-B罗克韦尔 处理器模块可以使用高达8 MB的用户内存和0.98 MB的输入/输出内存。此外，它总共有128，000个数字/0，最多有4000个模拟1/0。在1.2V DC下所需的电流消耗是5 mA，在5.1V DC下需要800 mA的电流消耗。1756-L73的功耗为2.5 W，散热为8.5BTU/小时。在基本绝缘条件下，隔离电压持续为30V，在500V交流电下测试60秒。使用USB 2.0，全速可以达到12 Mbps。约重0.25千克，1槽宽，开放式外壳
该模块在1756机箱系列的任何插槽中都是基于机箱的。1756-L73控制器的电源要求是标准的1756电源。它的接线类别是USB端口上的3。1756-L73控制器的工作温度为0-60摄氏度。它的非工作温度是-40-85摄氏度。摄氏度。它能工作的最高环境温度是60。5-95%非冷凝相对湿度，其工作振动为10 – 500 H，为2 g，工作冲击为30 g，非工作冲击为50 g，安装SD卡时可达459

1756-L73

The 1756-L73 A-B Rockwell processor module is capable of connecting 128,000 input and output signals and 4,000 analog input and output signals. It can implement a local I/0 configuration, where the I/0 module is installed in the same chassis where the controller is installed, or a distributed 1/0 topology, where the extended 1/0 is installed away from the processor and provided via an extended communication bus. The controller supports Ethernet I/P, DeviceNet, ControlNet, Synchlink, as well as traditional communication protocols such as Data Highway Plus (DH+), Remote l/0RI0, and third-party protocols, and it can also be configured to communicate with gateways and protocol converters. Similarly, the controller is compatible with the Ho Allen-Bradley encompose partnercontrollogix module.
1756-L73 A-B Rockwell Processor Module The controller also comes with integrated motion as it supports SERCOS interfaces, analog motion sensors and motion control on large network I/P. When programming the controller, the applicable programming languages include relay ladder diagram, structured text, function block diagram and sequence function diagram.
The controller is capable of handling 32 controller tasks with 100 programs per task, while the event task accepts all event triggers. The controller comes with 8MB of user memory and 0.98MB of I/O memory. It is also equipped with energy storage technology that eliminates the need to use batteries to preserve the contents of volatile memory.
The 1756-L73 A-B Rockwell processor module can use up to 8 MB of user memory and 0.98 MB of input/output memory. In addition, it has a total of 128,000 digital / 0s and a maximum of 4,000 analog 1/0s. The required current consumption is 5 mA at 1.2V DC and 800 mA at 5.1V DC. The 1756-L73 has a power consumption of 2.5 W and a heat dissipation of 8.5BTU/ hour. Under basic insulation conditions, the isolation voltage is sustained at 30V and tested at 500V AC for 60 seconds. With USB 2.0, full speed can reach 12 Mbps. Weighs about 0.25 kg, 1 slot wide, open housing
The module is chassis based in any slot of the 1756 chassis series. The power requirements for the 1756-L73 controller are the standard 1756 power supply. Its wiring category is 3 on the USB port. The 1756-L73 controller operates at 0-60 degrees Celsius. Its non-operating temperature is -40-85 degrees Celsius. Degrees Celsius. The maximum ambient temperature at which it can operate is 60. 5-95% non-condensing relative humidity, its working vibration is 10-500 H, is 2 g, working shock is 30 g, non-working shock is 50 g, up to 459 when SD card is installed
