2711-K6C5 Allen- Bradley 交流电源

目录号为2711-K6C5的PanelView标准操作员终端是来自2711-K6C5 Allen- Bradley 交流电源。该操作员终端更普遍地被称为人机界面(HMI),其主要目的是通过嵌入HMI内的特征组合，为过程操作员提供实时监控和过程界面。过程可视化通过5英寸彩色图形显示器实现，其中可以实现带有彩色编码信息的动画。这个彩色屏幕具有115x 86毫米(4.54X3.4英寸)的功能显示区域。)屏幕分辨率为320×234像素。屏幕配有内部背光，可现场更换，预计工作时间可达50，000小时
2711-K6C5 Allen- Bradley 交流电源由十(10)个功能键、导航和数字键组成的嵌入式键盘提供操作员控制和界面。每个键执行单独的功能，功能键能够接受本地和全局分配。这些键预计可启动100万次，并可与功能键图例插件一起安装
2711-K6C5具有DH485通信端口，可与艾伦-布拉德利的不同可编程逻辑控制器(PLC)产品兼容，如SLC 500、MicroLogix.CompactLogix和ControlLogix处理器。它还兼容第三方控制器和设备，实现过程可视化和集中监控

2711-K6C5

2711-K6C5是小型机器和过程的理想选择。它有一个内置的240KB非易失性存储器和190KB运行时应用程序存储器。它的额定电源输入范围为85-264伏交流电，频率为47-63赫兹。
2711-K6C5 Allen- Bradley 交流电源这台PV 600有一个生动的5英寸。彩色显示器。用户能够使用键盘控制HMI来输入信息和数据.
艺装置使用85-264伏交流电供电。该单元具有以下240 KB非易失性内存和190KB运行时内存，2711-K6C5 PanelView的可更背光为2711-NL3(适用于A系列和B系列设备)和2711-NL5(适用于C系列设备)。
RS-232(DH-485协议)终端使用DH-485协议连接到Micrologx和SLC 500控制器。点对点配置对高优先级数据使用单独的连接。他们还可以使用AIC+模块连接到DH-485网络
这一过程也可以通过RS-232打印机端口、标准RS-232/DH-85端口或PC存储卡(如2711-NM232)来完成

2711-K6C5

The PanelView Standard operator terminal with catalog number 2711-K6C5 is from the 2711-K6C5 Allen-Bradley AC power supply. More commonly known as the Human Machine Interface (HMI), the main purpose of this operator terminal is to provide real-time monitoring and process interface to process operators through a combination of features embedded within the HMI. Process visualization is achieved through a 5-inch color graphic display, where animations with color-coded information can be implemented. This color screen has a 115x 86 mm (4.54X3.4 inches) functional display area.) The screen resolution is 320×234 pixels. The screen has an internal backlight, can be replaced on site and has an estimated operating time of 50,000 hours
2711-K6C5 Allen-Bradley AC Power Supply An embedded keyboard consisting of ten (10) function keys, navigation, and numeric keys provides operator control and interface. Each key performs a separate function, and function keys can accept both local and global assignments. These keys are expected to launch 1 million times and can be installed with the function key legend plug-in
The 2711-K6C5 features a DH485 communication port and is compatible with different Allen Bradley Programmable Logic controller (PLC) products, such as the SLC 500, MicroLogix.CompactLogix, and ControlLogix processors. It is also compatible with third-party controllers and devices, enabling process visualization and centralized monitoring
The 2711-K6C5 is ideal for small machines and processes. It has a built-in 240KB non-volatile memory and 190KB run-time application memory. It has a rated power input range of 85-264 volts AC and a frequency of 47-63 Hz.
2711-K6C5 Allen-Bradley AC Power Supply This PV 600 has a vivid 5-inch. Color display. Users can use the keyboard to control the HMI to enter information and data.
The installation is powered by 85-264 volts AC. The unit has the following 240 KB of non-volatile memory and 190KB of runtime memory, and the 2711-K6C5 PanelView can be backlit 2711-NL3(for Series A and Series B devices) and 2711-NL5(for Series C devices).
RS-232(DH-485 protocol) terminals use the DH-485 protocol to connect to Micrologx and SLC 500 controllers. A peer-to-peer configuration uses separate connections for high-priority data. They can also connect to DH-485 networks using AIC+ modules
This process can also be done via an RS-232 printer port, a standard RS-232/DH-85 port, or a PC memory card such as 2711-NM232
