CI855K01 ABB 通信接口模块数据

制造商:ABB
产品编号:3BSE018106R1
产品型号:C1855K01 MB 300双以太网口接口
传输速度:10兆比特/秒，200个数据集/秒
CEX总线上的最大单位:12
连接器:RJ-45内螺纹(8针)
典型功耗为24 V。:150毫安
工作温度:55°C
防护等级:根据IEC 529 EN60529的IP20
尺寸(高x宽x深)，约为:18.5厘米x 5.9cm厘米x 12.75cm厘米
重量:0.7千克
装运重量:1.5千克
产品编号:3BSE018106R1 ABB型号名称:C1855K01目录描:CI855K01 MB 300接口长描:封装包括:-CI855，MB 300接口模块-TP853，基板类别产品控制系统产品控制与通信AC 800M AC 800M -通信模块CI855 MasterBus 300接口C1855K01 MB 300接口产品控制系统800xA控制器AC800M控制软件AC 800M控制软生40通信模块产品控制系统800XA控器AC 800M硬AC 800M4.0通信模块产品控制系统800xA控制器A800M硬件AC 800M4.1通信模块产品控制系统800xA控制器AC 800M .附如信息个质:包装包括:- CI855、MB300接口模块TP853、基板产品类型:通信 模块订购HS编码:851762-电话机，包括用于蜂窝网络或其他无线网络的电话;其他用于发送或接收声音、图像或其他数据的装置，包括用于有线或无线网络(如局域网或广域网)通信的装置，但税目84.43、85,25、85.27或85.28的发送或接收装置除外。

CI855K01

用于传输或接收语音、图像或其他数据的其他设备，包括用于在有线或无线网络(例如局域网或广域网)中进行通信的设备:-用于接收、转换和传输或再生语音恩像成其他数握的机器，与括本换和路中设备海关种则是·85176200寸产品净深度长度65 mm产品海度203 mm产品净157 mm品重:0.62 kg环境RoHS状态:遵循欧盟指令2011/65/欧盟WEEE类别小型设备(外部尺寸不超过50厘米)电池数量:0
ABB机器人创建信号及关联信号步骤车间ABB机器人较多，做改善或临时增加信号需要对机器人的信号进行配置，没有标准化流程，过程不清晰。1、创建信号之前先到要创建的模块里确认地址有没有被占用，创建组信号要查看组信号有没有包含在内的单个地址，创建单个信号要查看该信号有没有被别的组信号所包含。2、选择菜单，控制面板，配置系统参数，signal, 显示全部3、name:要创建的信号的名字;type of signal: 信号类型;assigned to device:要创建的信号 属于那个模块;device mapping:信号的地址。4、选择菜单，控制面板，配置系统参数，cross connection,显示全部5、name:要创建的关联信号的名称;resultant: 关联信号的结果;actor1:个条件;invert actor1:个条件是否取反;operator1:跟下 一个条件的关联关系;actor2:第二个条件; invert actor2:第二个条件是否取反;operator2:跟下一个条件的关联关系。

CI855K01

Manufacturer :ABB
Product Number :3BSE018106R1
Product model :C1855K01 MB 300 Dual Ethernet port
Transfer speed :10 megabits/SEC, 200 data sets/SEC
Maximum unit on the CEX bus :12
Connector :RJ-45 internal thread (8 pins)
Typical power consumption is 24 V. :150 mah
Operating temperature :55°C
Protection class: IP20 according to IEC 529 EN60529
Dimensions (H x W x D), approximately :18.5 cm x 5.9cm x 12.75cm
Weight :0.7 kg
Shipping weight :1.5 kg
Product Number :3BSE018106R1 ABB Model Name :C1855K01 Catalog Description :CI855K01 MB 300 Interface Long Description: Package includes :-CI855, MB 300 interface module -TP853, Baseboard Category Product Control System Product Control and Communication AC800M AC800M – Communication module CI855 MasterBus 300 interface C1855K01 MB 300 Interface Product Control System 800xA Controller AC800M Control software AC 800M control Software 40 Communication module Product control System 800XA controller AC 800M Hard AC 800M4.0 Communication module Product control system 800xA controller A800M Hardware AC 800M4.1 Communication module Product control system 800xA controller AC 800M. The package includes :- CI855, MB300 interface module TP853, substrate product type: Communication module order HS code :851762- telephone, including telephones for cellular networks or other wireless networks; Other devices used to transmit or receive sound, images or other data, including devices used to communicate over a wired or wireless network, such as a local or wide area network, other than transmitting or receiving devices under heading 84.43, 85,25, 85.27 or 85.28.
– Other equipment used to transmit or receive voice, images or other data, including equipment used to communicate in a wired or wireless network (such as a local area network or a wide area network) :- Machines used to receive, convert and transmit or reproduce voice data into other data sets, The customs type of equipment with this replacement and road is ·85176200 inch product Net depth Length 65 mm product sea degree 203 mm product net 157 mm product weight :0.62 kg Environmental RoHS status: comply with EU Directive 2011/65/ EU WEEE category Small equipment (external size does not exceed 50 cm) Number of batteries :0
There are many ABB robots in the workshop to create signals and associate signals. To improve or temporarily increase signals, the signals of robots need to be configured. There is no standardized process and the process is not clear. 1, before creating a signal, go to the module to be created to confirm whether the address is occupied, create a group signal to check whether the group signal is included in a single address, create a single signal to check whether the signal is included in other group signals. 2. Select Menu, Control Panel, and configure system parameters, signal, to display all 3. name: indicates the name of the signal to be created. type of signal; type of signal; assigned to device: Which module the signal to be created belongs to; device mapping: indicates the address of a signal. 4, select menu, Control panel, configure system parameters, cross connection, display all 5, name: to create the name of the associated signal; resultant: The result of the associated signal; actor1: a condition; invert actor1: whether a condition is inverted; operator1: association with the next condition; actor2: Second condition; invert actor2: whether the second condition is inverted; operator2: The relation to the next condition.
