CI871K01 ABB 通信接口

CI871A是通过以太网连接到PROFINET 0设备的AC 800M通信接口。TP867 Baseplate有两RJ45以太网连接器，但只有支持100Mbps的CH1连接器用于PROFINETIO连接。以太网电缆必须通过以太网交换机连接到PROFINET O网络。CI871扩展单元包含CEX总线逻辑、通信单元和DC/DC转换器，用于通过CEX总线提供所需电压+24 V。CI871A模块仅适用于System 800xA 6.0.3.3、6.1.1和更高版本
CI871A是一个AC 800M通信接口，通过以太网与PROFINET 0设备连接TP867 Baseplate有两RJ45以太网连接器，PROFINET I0连接只使用支持100Mbps的CH1连接器。以太网线缆必须通过以太网交换机连接到PROFINET O网络C1871扩展单元包含CEX-Bus逻辑、通信单元和DC/DC转换器，该转换器从+ 24v电源通过CEX-Bus提供所需电压.CI871A模块只适用于Svstem 800xA 6.0.3.3、6.1.1和后续版本

CI871K01

特点和优点
通过以太网连接PROFINETIO设备
介质描述:封装包括: – CI871，通信接口- TP867，底板产品类型: Communication Module订购海关编码: 851762-电话机，包括用于蜂窝网络或其他无线网络的电话:用于传输或接收语音、图像或其他数据的其他设备，包括在有线或无线网络(诸如局域网或广域网)中进行通信的设备，但标题为84.43、85.25、85.27或85.28的传输或接收设备除外。包括在有线或无线网络(如局域网或广域网)中进行通信的设备:-用于接收、转换和传输或再生语音、图像或其他数据的机器，包括交换和路由设备海关关税号: 8517620000尺寸产品净深度/长度:127.5 毫米产品净高:185 毫米产品净重:59 毫米产品净重: 0.65 千克环境的ROHS 状态:遵循欧盟指令 2011/65/EU报废电子电气设备类别: 5,小型设备(部尺寸不超过50厘米) 电池数量: 0

CI871K01

The CI871A is an AC 800M communication interface connected to the PROFINET 0 device over Ethernet. The TP867 Baseplate has two RJ45 Ethernet connectors, but only the 100Mbps CH1 connector is used for PROFINETIO connectivity. The Ethernet cable must be connected to the PROFINET O network through an Ethernet switch. The CI871 expansion unit contains the CEX bus logic, communication unit, and DC/DC converter to provide the required voltage +24 V over the CEX bus. The CI871A module is only available for System 800xA 6.0.3.3, 6.1.1 and later
The CI871A is an AC 800M communication interface that connects to the PROFINET 0 device over Ethernet. The TP867 Baseplate has two RJ45 Ethernet connectors, and the PROFINET I0 connection uses only the CH1 connector that supports 100Mbps. Ethernet cables must be connected to the PROFINET O network via an Ethernet switch. The C1871 expansion unit contains the CEX-Bus logic, communication unit, and DC/DC converter that provides the required voltage from a + 24v power supply via the CEX-Bus. The CI871A module is only available for Svstem 800xA 6.0.3.3, 6.1.1 and later versions
Features and advantages
Connect PROFINETIO devices over Ethernet
Media description: Package includes: -CI871, Communication interface -TP867, baseboard Product type: Communication Module Order Customs Code: 851762- Telephone sets, including telephones for cellular or other wireless networks: other devices used to transmit or receive voice, images, or other data, including devices for communication in wired or wireless networks such as local or wide area networks, Except for transmission or receiving devices with headings 84.43, 85.25, 85.27 or 85.28. Includes equipment that communicates in wired or wireless networks (such as local or wide area networks) :- Machines used to receive, convert and transmit or regenerate voice, images or other data, including switching and routing equipment 8517620000 Size Product Net depth/Length :127.5 mm Product net height :185 mm Product Net weight :59 mm product net weight: 0.65 kg Environmental ROHS status: Compliance with EU Directive 2011/65/EU Waste electrical and electronic equipment Category: 5, small equipment (part size does not exceed 50 cm) Number of batteries: 0

CI871K01
