D138-002-002 MOOG 控制器

MSC I和MSC II运动控制器是具有PLC功能的高性能运动控制器，非常适合复杂的集中式和分散式应用。这些模块是为类似类型的任务设计的，只是接口和性能不同。这些运动控制器具有内置的IP20保护，并安装在电子机柜中的DIN导轨上MSC I运动控制器提供高分辨率模拟输入/输出和位置传感器接口它设计用于快速准确地闭环控制两轴，MSC I运动控制器最适合需要通过模拟接口控制一个或两个执行器的应用MSC ll运动控制器具有多个现场总线接口和四个位置传感器接口。它设计用于闭环控制，包括或不包括多个电动或液压轴的轮廓生成。MSC I和MSC II运动控制器的综合功能可以通过额外的高分辨率分析和数字l/0以及通信模块来扩展。扩展模块夹在运动控制器的侧面，并通过内部扩展总线（e总线）进行电子连接。为了控制复杂的分散应用，包括两个CAN总线接口

MOOG D136-002-005带D138-002-00

M128-010 M128-010-A001B

D136-001-007

D138-002-002

穆格MOOG控制器D138-002-002加密狗也称密码狗，是一款账号、密码管理工具，比如银行，游戏，软件，账户等等一系列的密码，只要记住一个密码就可以了，这个是不是很关键？

穆格MOOG控制器D138-002-002加密狗是一种高性能的伺服控制器，带有PLC功能，并配备高分辨率的模拟输入/输出和位置传感器接口。其特殊的结构设计，可快速、精确地实现双液压伺服作动器的闭环控制。
穆格MOOG目前正在开发其第三代穆格MOOG运动控制器MSC III。

新型号结合了MSC I（例如集成模拟接口）的所有优点

MSC II提供的功能（如EtherCAT等实时现场总线接口）整合为一个经济高效的

单元此新控制器提高了整体性能，包括其他高级功能和

可与新的穆格MOOG应用软件套件（MASS）配合使用。

D138-002-002

The MSC I and MSC II motion controllers are high-performance motion controllers with PLC functionality, ideal for complex centralized and decentralized applications. These modules are designed for similar types of tasks, with different interfaces and performance. These motion controllers have built-in IP20 protection and are mounted on a DIN rail in an electronic cabinet. The MSC I motion controller provides a high-resolution analog input/output and position sensor interface. It is designed for fast and accurate closed-loop control of both axes. The MSC I motion controller is best suited for applications where one or two actuators need to be controlled via an analog interface The MSC ll motion controller has multiple fieldbus interfaces and four position sensor interfaces. It is designed for closed-loop control with or without profile generation of multiple electric or hydraulic shafts. The combined capabilities of the MSC I and MSC II motion controllers can be extended with additional high-resolution analysis and digital l/0 and communication modules. The expansion module clips to the side of the motion controller and is electronically connected via an internal expansion bus (e-bus). To control complex decentralized applications, two CAN bus interfaces are included

MOOG D136-002-005 with D138-002-00

M128-010 M128-010-A001B

D136-001-007
MOOG MOOg controller D138-002-002 Dongle also known as password dog, is an account, password management tools, such as banks, games, software, accounts and so on a series of passwords, as long as remember a password can be, this is not very key?

The MOOG Controller D138-002-002 Dongle is a high performance servo controller with PLC capability and a high resolution analog input/output and position sensor interface. The special structure design can realize the closed-loop control of double hydraulic servo actuators quickly and precisely.
MOOG MOOG is currently developing its third generation Moog Moog motion controller, the MSC III.

The new model combines all the benefits of the MSC I, such as the integrated analog interface

The functionality provided by MSC II (such as EtherCAT and other real-time fieldbus interfaces) is integrated into a cost-effective

Unit This new controller improves overall performance, including other advanced features and

Works with the new MOOG Suite of Applications (MASS).

D138-002-002
