GEDS200DCFBG1BGB 电流反馈卡

GEDS200DCFBG1BGB 电流反馈卡 DS200SDCCG1AFD
有关反馈的定义与概念，什么是反馈，将输出量(电压或电流)的一部分或全部通过一定的电路形式作用到输入回路，用来影影响其输入量(放大电路的输入电压或输入电流)的措施称为反馈。一、什么是反馈在电子电路中，将输出量(电压或电流)的一部分或全部通过一定的电路形式作用到输入回路，用来影影响其输入量 (放大电路的输入电压或输入电流)的措施称为反馈。二、反馈的定义“反馈的定义定义1:系统过去的行为结果返回给系统，以控制未来的行为。定义2:部分信号从双端口网络输出端向输入端的回传，或从传输通道上的一点向途中已通过的一点的回传

DS200DCFBG1BGB

DS200DCFBG1B是通用电气公司为Mark V板系列生产的电源板，AC2000、CB2000、DC2000、FC2000ME2000和EX2000系列机器可以将板安装在驱动器中。安装后，此卡可以提供控制级电源和机箱风扇电源去车道，额定电压在38到115伏之间可以通过控制电源变压器直接提供给电路板。电路板的频率取决于输入电压，但范围可以从0至500千赫
该板具有许多电路，用于为板和安装的驱动器供电，DS200DCFBG1B包括电机磁场电源、驱动器、交流/DC监控和控制级电源电路。这十二个跳线和七DIP开关为用户提供可配置的系统洗项，保险丝开关诊断使用两LED和一个雷虹灯指示灯在黑板上找到的。二个保护保险丝防止电源中断，可以使用监控电压五个测试点集成在电路板上
应遵循制造商提供的DS200DCFBG1B和已安装驱动器的安装和存储参数，这将防止对两个单元的任何意外或可预防的损坏。有关电路板布线和安装的完整指南，请参考设备手册和数据表。最初，该板和Mark V系列的技术支持由制造商通用电气公司提供。

DS200DCFBG1BGB

GEDS200DCFBG1BGB Current Feedback card DS200SDCCG1AFD
The definition and concept of feedback, what is feedback, part or all of the output (voltage or current) through a certain circuit form to the input loop, used to influence its input (input voltage or input current of the amplifier circuit) measures called feedback. In an electronic circuit, a part or all of the output (voltage or current) is applied to the input loop through a certain circuit form, and the measure used to influence its input (the input voltage or input current of the amplifier circuit) is called feedback. Definition of feedback Definition 1: The results of past behavior of the system are returned to the system to control future behavior. Definition 2: Part of the signal is transmitted back from the output to the input of a two-port network, or from a point on the transmission channel to a point that has passed along the way
The DS200DCFBG1B is a power board produced by General Electric for the Mark V board series, which can be mounted in a drive for AC2000, CB2000, DC2000, FC2000ME2000 and EX2000 series machines. When installed, the card can provide control level power and chassis fan power to the lane, and the rated voltage between 38 and 115 volts can be supplied directly to the board via the control power transformer. The frequency of the board depends on the input voltage, but can range from 0 to 500 KHZ
The board has a number of circuits for powering the board and mounted drivers, and the DS200DCFBG1B includes a motor field power supply, a driver, AC /DC monitoring and control-level power circuits. The twelve jumpers and seven DIP switches provide users with configurable system wash items, and the fuse switch diagnostics are found using two leds and a thunderbow indicator light on the board. Two protective fuses prevent power outages and can be used to monitor voltage with five test points integrated on the circuit board
The installation and storage parameters of DS200DCFBG1B and installed drives provided by the manufacturer should be followed, which will prevent any accidental or preventable damage to both units. For complete guidelines on circuit board wiring and installation, refer to the device manual and data sheet. Initially, technical support for the board and the Mark V series was provided by manufacturer General Electric.

DS200DCFBG1BGB
