ETT-VGA 模拟显示器

ECT-VGA和ETT-VGA满足了对功能强大但具有成本效益的操作员接口系统的需求。显示器是基于像素的16色LCD，具有VGA分辨率，采用TFT有源矩阵或无源彩色STN。

这些像素可寻址显示器允许我们的Designer for Windows软件包提供图形功能。每行最多可包含80个字符。每页最多可包含30行。提供亮度控制以调整显示器，以便在几乎任何条件下都能轻松观看。显示变量PLC内部变量可以显示在许多显示页面中的任何一个页面上。一次可以查看的变量数量仅受显示大小的限制。
UniOP还提供显示数据的缩放（线性转换）。最终值可以用几种有用的格式显示，包括条形图、日期、时间、十进制、位、十六进制、浮点和字符串。

每种数据类型都可以输入有效范围验证的数据。数据输入ECT-VGA和ETT-VGA为用户提供八个可配置的功能键和八个用户可定义的LED。模拟触摸屏增加了创建小到单个字符或大到整个屏幕的触摸单元的能力。

UniOP还配备了内置电池支持的实时时钟。来自时钟的时间和日期信息在PLC中定期更新，以实现基于一天中的时间、星期几或任何其他周期的处理。安全八级密码保护方案可保护关键系统功能免受意外访问。

报警UniOP可以监控和显示多达1024个报警。可以定义每个警报的属性和唯一消息。也可能需要操作员确认。UniOP检测到的最后256个报警事件保留在内部事件列表中。此列表可以在屏幕上查看，也可以在串行打印机上打印以获得永久记录。

ETT-VGA

ETT-VGA模块
*密度范围从4点到32点，每个模块。
*模块率IP20，I类，2/Z0IE 20
某些模块具有现场侧诊断，电子熔断，或单独隔离的输入/输出。一个远程端子块(TB)或线系统需要为每个/模块。
ControlLogix电源 ?使用ControlLogix电源1756机箱直接到机箱背板提供1.2V，3.3V，5V和24V直流电源。
?每个机箱中选择一个电源，如果你使用的是标准的电源。
洗择电源捆绑在一起，如果你打算-个余电源系统的ControlLogix 机箱 MCntrolLogix标准的ControlLogix-XT底盘选择。标准机箱有4，7，10，13，或17个插槽的ControlLogix-XT底盘是5或7个插槽。插槽填充所需要的空插槽。可选的系统组件包括:操作界面和电脑我们的人机界面和计算机产品，以及与L0B1x控制和通信VetLi架构，使罗克韦尔自动化集成架构策略。
*选择的PanelView Flus的PelView Plus E电子操作员接口和罗克韦尔自动化的工业化个人电脑硬件。可洛软件监控软件FactoryTalk Vew软件。软件您选择的模块和网络配置确定的软件包你需要你的系统进行配和编程*编程ControlLogix系统RSLogix 5000 Enterprise系列软件。

ETT-VGA

ECT-VGA and ETT-VGA address the need for a powerful yet cost-effective operator interface system. The display is a pixel-based 16-color LCD with VGA resolution using either a TFT active matrix or a passive color STN.

These pixel addressable displays allow our Designer for Windows packages to provide graphics capabilities. Each line can contain up to 80 characters. Each page can contain up to 30 lines. Brightness control is provided to adjust the display for easy viewing in almost any conditions. Display variables PLC internal variables can be displayed on any one of many display pages. The number of variables that can be viewed at a time is limited only by the size of the display.
UniOP also provides scaling (linear conversion) of the display data. The final value can be displayed in several useful formats, including bar chart, date, time, decimal, bit, hexadecimal, floating point, and string.

Each data type can be entered with valid range validation. Data entry ECT-VGA and ETT-VGA provide users with eight configurable function keys and eight user-definable leds. Analog touch screens increase the ability to create touch units as small as a single character or as large as an entire screen.

The UniOP also comes with a real-time clock with built-in battery support. The time and date information from the clock is regularly updated in the PLC to enable processing based on the time of day, day of the week, or any other cycle. Secure eight-level password protection protects critical system functions from accidental access.

Alarm UniOP can monitor and display up to 1024 alarms. Attributes and unique messages can be defined for each alert. Operator confirmation may also be required. The last 256 alarm events detected by UniOP remain in the internal event list. This list can be viewed on the screen or printed on a serial printer for a permanent record.
ETT-VGA module
* Density ranges from 4 to 32 points per module.
* Module rate IP20, Class I, 2/Z0IE 20
Some modules have field side diagnostics, electronic fuses, or individually isolated inputs/outputs. A remote terminal block (TB) or wire system is required for each/module.
ControlLogix power supply? Use the ControlLogix power supply 1756 chassis to provide 1.2V, 3.3V, 5V and 24V DC power directly to the chassis backplane.
? Select a power supply in each case, if you are using a standard power supply.
Wash the optional power supply bundled together if you plan to – a residual power system for the ControlLogix chassis MCntrolLogix standard ControlloGIX-XT chassis option. The standard chassis has 4,7,10,13, or 17 slots – the ControlLogix-XT chassis is 5 or 7 slots. Slot fills the required empty slot. Optional system components include: Operating interfaces and computers our HMI and computer products, as well as an integrated architecture strategy with the L0B1x control and communication VetLi architecture that enables Rockwell Automation.
* Selected PanelView Flus PelView Plus E electronic operator interface and Rockwell Automation industrial PC hardware. Kolo Software Monitoring software FactoryTalk Vew software. Software You select the module and network configuration to determine the package you need for your system to be configured and programmed * Program ControlLogix System RSLogix 5000 Enterprise series software.

ETT-VGA
