HYDRAN M2变压器油中故障气体在线监测系统
一般规格
基于已经现场验证的技术，新的Hydran M2增加 了基于IEEE®和IEC®标准的变压器数学模型，从 而可以提供实时的变压器概况信息。这样就不仅 仅是只监控溶解气体和湿度，而是拓展到对变压 器更多故障形式的监控。
当一台重要变压器发生不可预知的故障的时候， 就会对电网的运行和经济性产生严重的影响。当 今，许多电网和工业用户的油浸式变压器都接近 了设计寿命的底线，并且表现出明显的故障率升 高。对电力供应的严格规定，投资和操作费用的 预算的减少，和专业技术人员的短缺都需要延长 这些变压器的使用寿命。
描述
Hydran M2是经济的，它是功能强大的一体化变 压器监控装置，它允许电网和其他用户部署对众 多变压器的监控，并且会从它先进的特性中得到 收益。
Hydran M2早期故障报警模型通过在线故障气体 和湿度传感器对变压器和其他油浸式设备早期故 障进行监控。附加的数字和模拟量输入允许对变 压器其他变量的监控。新的变压器模型拓展了Hydran M2的监控能力和资产管理能力，这可以 对设备操作和维护人员提供更多的决策帮助。
HYDRAN-M2
系统特性
• 实时油中故障气体和湿度测量系统
• 不允许真空的气体萃取膜
• 单独阀门安装，不需要附加泵和移动部件
• 基于微处理器的智能电子装置 • 全系统自测和自我诊断
• NEMA 4X(IP66) 外壳
• 数字化显示，可翻屏控制
• 4个用于报警的可编程继电器
• 1个自检继电器触点
• 4个扩展I/O 插头接头，需要结合如下板卡 -隔离4-20mA 模拟输入卡 -隔离双通道数字输入卡 -隔离4-20mA 模拟输出卡
• 1个通讯扩展插头接头 -以太网10-100Base T 卡 -模拟调制解调器
• 就地隔离RS-232串行接口
• 远方连接隔离RS-485串行接口
• 支持DNP3规约（串行接口或者TCP/IP）
• 扩展的可调整频率数据和事件日志
• 可调整的关于气体，湿度，模拟输入和变压器 模型计算的基于水平和趋势的报警设置
• 友好的客户机/服务器图形化使用者界面 （GUI），允许多客户机通过TCP/IP 接入
HYDRAN-M2
HYDRAN M2 on-line monitoring system for faulty gas in transformer oil
General specification
Based on field-proven technology, the new Hydran M2 adds a mathematical model of the transformer based on IEEE® and IEC® standards to provide real-time transformer overview information. This is not only to monitor dissolved gas and humidity, but also to expand the monitoring of more failure forms of the transformer.
When an important transformer has an unpredictable failure, it will have a serious impact on the operation and economy of the power grid. Today, many oil-immersed transformers for power grids and industrial users are approaching the bottom line of their design life and show a significant increase in failure rates. Strict regulations on power supply, reduced budgets for investment and operating costs, and a shortage of specialized technicians all require extending the service life of these transformers.
Description
The Hydran M2 is an economical, powerful, all-in-one transformer monitoring device that allows power grids and other users to deploy monitoring of multiple transformers and benefit from its advanced features.
The Hydran M2 Early Failure Alarm model monitors early failure of transformers and other oil-immersed equipment with in-line failure gas and humidity sensors. Additional digital and analog inputs allow monitoring of other transformer variables. The new transformer model expands the monitoring and asset management capabilities of the Hydran M2, which provides more decision-making assistance to equipment operators and maintenance personnel.
System characteristic
• Real-time faulty gas and humidity measurement system in oil
• Does not allow vacuum gas extraction membrane
• Separate valve installation, no additional pumps and moving parts required
• Intelligent electronic devices based on microprocessors • System-wide self-testing and self-diagnosis
• NEMA 4X(IP66) housing
• Digital display, reversible screen control
• 4 programmable relays for alarm
• 1 self-checking relay contact
• Four expansion I/O plugs need to be combined with the following boards – isolated 4-20mA analog input cards – Isolated dual-channel digital input cards – isolated 4-20mA analog output cards
• 1 Communication expansion connector – Ethernet 10-100Base T card – Analog modem
• Isolated RS-232 serial interface in place
• Remote connection isolated RS-485 serial interface
• Support DNP3 protocol (serial interface or TCP/IP)
• Extended adjustable frequency data and event logging
• Adjustable level and trend-based alarm Settings for gas, humidity, analog input and transformer model calculations
• User-friendly client/server graphical user interface (GUI) that allows multi-client access over TCP/IP
