IC695CPE310 GE 控制器

部件号IC695CPE310
外形背板
用户内存13MB
I/O32k 位离散量 I/O，32k 字模拟量 I/O
能量包随附
冗余支持介质冗余 (MRP)，带 PNC001
以太网端口3 – 2 端口开关 10/100/1000
以太网协议SRTP 客户端/服务器，Modbus TCP/IP，OPC UA，EGD，PROFINET，DNP3 电站，IEC-61850 客户端，IEC-104 服务器，HART Passthrough
串行协议ASCII 串行协议，Modbus/RTU
远程 I/O 设备255 单工，带 PNC001
USB 接口1 个 USB-A 2.0
环境0 至 60℃
机构认证UKCA，UL，cUL，RoHS，CCC，FCC，Reach，UL HazLoc C1D2，ATEX Zone 2
海事认证ABS，BV，LRDNV GL基于标签的编程等编程工具，可重用代码库，可改进在线故障排除的测试编辑模式
用户友好环境，可提高设计灵活性并提高工程效率和生产率
支持 PROFINET 的设备增加即插即用功能，便于安全地连接机器、数据和人员
高速多核处理器，可提高吞吐量，无任何信息瓶颈
支持高密度离散量 I/O 模块、通用模拟量模块（每个通道均可配置 TC、RTD、应变仪、电压和电流）、隔离模拟量模块、高密度模拟量模块、高速计数器和运动模块

IC695CPE310

孤立的串行端口实现传感器和仪器之间稳定可靠的集成
IC695CPE310是GE Fanuc PACSystem RX3i系列中的一款CPU。CPU可以对机器、流程和材料处理系统进行实时控制。它通过两用PCI和串行背板与I/O和智能选项模块通信。
IC695CPE310拥有1.1 GHz的Atom处理器和10 MB的内存。其嵌入式以太网接口支持10Mb/秒和100 MB/秒的两种连接。它还具有RS-485和RS-232串行端口。该模块支持多达512个程序块，每个程序块可达128 KB。
IC695CPE310包含Modbus RTU从机、SNP和串行I/O协议，同时使用SNP协议与人机界面(HMI)设备通信。
您可以用梯形图、结构化文本、C或功能块图编程语言对IC695CPE310进行编程。当设备通电时，设备外壳上贴有标签的led指示灯可以是绿色、红色、熄灭或闪烁。这将提高故障排除的效率，并让您可以一目了然地验证系统状态。
IC695CPE310可以安装在主RX3i控制器机架的任何一对插槽中，编号最高的两个插槽除外。
IC695CPE310中的处理器比C695CPU310中的300 MHz赛扬处理器快大约三倍。您可以从CPU310升级到CPE310，而无需更改原有的PME软件。请注意，如果您决定从CPU310升级到CPE310，则CPE310上的RS-232端口不会在引脚5上提供5V电源。

IC695CPE310

Part number IC695CPE310
Contour backplane
User memory 13MB
I/O32k bit discrete I/O, 32k word analog I/O
Energy packs are included
Redundancy Supports media redundancy (MRP) with PNC001
Ethernet port 3-2 Port switch 10/100/1000
Ethernet Protocol SRTP client/server, Modbus TCP/IP, OPC UA, EGD, PROFINET, DNP3 power Station, IEC-61850 client, IEC-104 server, HART Passthrough
Serial Protocol ASCII Serial protocol, Modbus/RTU
Remote I/O device 255 simplex with PNC001
USB port One USB-A 2.0
Environment 0 to 60℃
Agency certification UKCA, UL, cUL, RoHS, CCC, FCC, Reach, UL HazLoc C1D2, ATEX Zone 2
Maritime Certification ABS, BV, LRDNV GL Tag based programming and other programming tools, reusable code base, improve test editing mode for online troubleshooting
User-friendly environment for increased design flexibility and improved engineering efficiency and productivity
Profinet-enabled devices add plug-and-play capabilities to securely connect machines, data, and people
High speed multi-core processor for increased throughput without any information bottlenecks
Supports high-density discrete I/O modules, universal analog modules (TC, RTD, strain gauge, voltage and current can be configured per channel), isolated analog modules, high-density analog modules, high-speed counters and motion modules
Isolated serial ports enable stable and reliable integration between sensors and instruments
The IC695CPE310 is a CPU in the GE Fanuc PACSystem RX3i family. The CPU provides real-time control of machines, processes, and material handling systems. It communicates with the I/O and Smart Options modules via dual-purpose PCI and serial backplanes.
The IC695CPE310 has a 1.1GHz Atom processor and 10 MB of RAM. Its embedded Ethernet interface supports both 10Mb/ s and 100MB/s connections. It also has RS-485 and RS-232 serial ports. The module supports up to 512 blocks of 128 KB each.
The IC695CPE310 contains the Modbus RTU slave, SNP, and serial I/O protocols, while using the SNP protocol to communicate with human machine interface (HMI) devices.
You can program the IC695CPE310 in ladder diagram, structured text, C, or function Block diagram programming languages. When the device is powered on, the labeled led indicator on the device housing can be green, red, off, or blinking. This increases the efficiency of troubleshooting and allows you to verify system status at a glance.
The IC695CPE310 can be installed in any pair of slots in the main RX3i controller rack, except for the two highest-numbered slots.
The processor in the IC695CPE310 is about three times faster than the 300 MHz Ceon processor in the C695CPU310. You can upgrade from CPU310 to CPE310 without changing your original PME software. Note that if you decide to upgrade from CPU310 to CPE310, the RS-232 port on the CPE310 will not provide 5V power on pin 5.
