MVI56E-MNETC PROSOFT 网络接口模块

特性
提供Modbus TCP/IP和以太网/IP网络之间的连接
支持多达256个Modbus TCP/IP客户端和服务器
支持多达128个以太网/IP扫描仪和适配器连接
提供灵活的数据映射选项
允许与现有自动化系统轻松集成
支持冗余电源配置
提供内置的诊断和故障排除工具
通过基于web的界面提供简单的配置和设置

参数
电源:5V DC
工作温度:-40℃~ 70℃
储存温度:-40℃~ 85℃
尺寸:4.875 ” x 1.05 ” x 5.75 ”
重量:0.25磅

MVI56E-MNETC

MVI56E-MNETC/MNETCXT 是首选模块。Modbus TCP/IP 增强型通信模块允许 Rockwell Automation® ControlLogix® 可编程自动化控制器 (PAC) 与 Modicon® 可编程自动化控制器 (PAC) 以及多个 Modbus TCP/IP 服务器兼容仪器和设备轻松连接。多客户端模块通过支持多达 30 个客户端，提高了在 Modbus TCP/IP 网络上控制多个服务器时的性能。它还支持多达 20 个服务器连接，提供与其他 DCS 和 SCADA 系统通信的能力。客户端和服务器功能可以同时运行，使该模块可以作为强大的数据集中器运行。

MVI56E-MNETC 和 MVI56E-MNETCXT 在功能上是相同的。MVI56E-MNETC 专为标准过程应用而设计。MVI56E-MNETCXT 专为 Logix-XT 控制平台设计，使其能够在极端环境中运行。它可以承受更高的工作温度，并具有保形涂层以保护其免受恶劣或腐蚀性条件的影响。

MVI56E-MNETC

peculiarity
Provides connectivity between Modbus TCP/IP and Ethernet /IP networks
Supports up to 256 Modbus TCP/IP clients and servers
Supports up to 128 Ethernet /IP scanner and adapter connections
Provides flexible data mapping options
Allows easy integration with existing automation systems
Supports redundant power supply configuration
Provides built-in diagnostic and troubleshooting tools
Simple configuration and setup via a web-based interface

argument
Power supply :5V DC
Operating temperature :-40℃~ 70℃
Storage temperature :-40℃~ 85℃
Size :4.875 “x 1.05″ x 5.75”
Weight :0.25 pounds
MVI56E-MNETC/MNETCXT is the preferred module. The Modbus TCP/IP Enhanced communication module allows Rockwell Automation® ControlLogix® Programmable Automation Controller (PAC) with Modicon® Programmable Automation Controller (PAC) and multiple Modbus TCP/IP The server is compatible with instruments and devices for easy connection. The multi-client module improves performance when controlling multiple servers over Modbus TCP/IP networks by supporting up to 30 clients. It also supports up to 20 server connections, providing the ability to communicate with other DCS and SCADA systems. Client and server functions can be run simultaneously, allowing the module to run as a powerful data concentrator.

The MVI56E-MNETC and MVI56E-MNETCXT are functionally identical. The MVI56E-MNETC is designed for standard process applications. The MVI56E-MNETCXT is designed for the Logix-XT control platform, enabling it to operate in extreme environments. It can withstand higher operating temperatures and has a conformal coating to protect it from harsh or corrosive conditions.

MVI56E-MNETC
