MVI56-PDPMV1 PROSOFT 处理器

系统需求
MVI56-PDPMV1模块需要以下最低硬件和
软件组件:
•罗克韦尔自动化ControlLogix处理器，具有兼容的电源
在机架上有一个空闲槽，用于MVI56-PDPMV1模块。该模块
需要800ma的可用功率。
罗克韦尔自动化RSLogix 5000编程软件版本2.51或
更高的
•罗克韦尔自动化RSLinx通信软件
Pentium®
II 450mhz最低。Pentium III 733 MHz(或更高)
推荐

MVI56-PDPMV1

屏幕上显示安装程序的说明。
安装模块到机架
如果您还没有安装和配置ControlLogix处理器和
请在安装MVI56-PDPMV1模块前关闭MVI56-PDPMV1的电源开关。请参考
警告:在安装这个或任何其他电子设备时，您必须遵守所有安全说明
设备。不遵守安全程序可能会导致硬件或数据损坏，甚至导致设备损坏
人员严重受伤或死亡。请参考您计划使用的每个设备的文档
在安装或维修设备之前，请连接以验证适当的安全程序是否到位
设备。
警告:在背板通电的情况下插拔模块时，会产生电弧
可能发生的。这可能会导致危险地点装置的爆炸。验证功率是否为
在进行前移除或该区域无危险。反复电弧的原因
模块及其配套连接器上的触点磨损过度。磨损的隐形眼镜
产生可能影响模块运行的电阻。

MVI56-PDPMV1

System requirement
The MVI56-PDPMV1 module requires the following minimum hardware and
Software components:
• Rockwell Automation ControlLogix processor with compatible power supply
There is a free slot in the rack for the MVI56-PDPMV1 module. This module
800ma of available power is required.
Rockwell Automation RSLogix 5000 Programming software version 2.51 or
higher
• Rockwell Automation RSLinx communication software
 Pentium ®
II 450mhz minimum. Pentium III 733 MHz(or higher)
Recommended

Instructions for installing the program are displayed on the screen.
Install the module into the rack
If you have not already installed and configured the ControlLogix processor and
Before installing the MVI56-PDPMV1 module, turn off the power switch of the MVI56-PDPMV1. Please refer to
Warning: You must follow all safety instructions when installing this or any other electronic device
Equipment. Failure to follow security procedures may result in damage to hardware or data, or even damage to the device
People are seriously injured or killed. Refer to the documentation for each device you plan to use
Before installing or servicing equipment, connect to verify that proper safety procedures are in place
Equipment.
Warning: Electrical arcs may occur when inserting or removing a module with power on the backplane
It could happen. This could lead to the explosion of a device in a dangerous location. Verify that the power is
Remove before proceeding or the area is not in danger. Cause of repeated arcing
Excessive contact wear on the module and its accompanying connectors. Worn contact lenses
Generates resistance that may affect module operation.

MVI56-PDPMV1
