VME7740-841 机械保护系统 状态和性能监测系统

采用VM600Mk2/VM600 RPS6U机柜电源

设计用于VM600Mk2/VM600

系列机械保护系统及

状态和性能监测系统;

来自麦吉特振动计®产品线。

VM600Mk2/VM600 RPS6U机柜电源为

安装在VM600Mk2/VM600 ABE04x的前部

系统机架(19个″系统机架标配)

高度6U)，并通过两个大电流连接

连接到机架的VME总线

底板。RPS6U电源提供

+5 VDC和±12 VDC到机架本身和所有

通过机架安装模块(卡)到机架

底板。
VME（Versa Module Europa）总线是一种并行计算机总线，设计用于满足空间应用、高可靠性、模块化及高性能等要求。VME64x扩展了标准的VME32/64总线功能，提供了一种高性能、高性价比的解决方案，满足了更广泛的应用需求。
VME（VersaModule Eurocard）总线是一种通用的计算机总线，结合了Motorola公司Versa总线的电气标准和在欧洲建立的Eurocard标准的机械形状因子，是一种开放式架构。
它定义了一个在紧密耦合（closely coupled）硬件构架中可进行互连数据处理、数据存储和连接外围控制器件的系统。经过多年的改造升级，VME系统已经发展的非常完善，围绕其开发的产品遍及了工业控制、军用系统、航空航天、交通运输和医疗等领域。

VME7740-841

Use the VM600Mk2/VM600 RPS6U cabinet power supply

Designed for VM600Mk2/VM600

Series mechanical protection system and

Condition and performance monitoring system;

From the Meggit Vibrometer ® product line.

The power supply of the VM600Mk2/VM600 RPS6U cabinet is

It is installed on the front of the VM600Mk2/VM600 ABE04x

System racks (19 “system racks as standard)

Height 6U) and connected by two large currents

Connect to the VME bus of the rack

The bottom plate. RPS6U power supply

+5 VDC and ±12 VDC to the rack itself and all

Install modules (cards) into the rack through the rack

The bottom plate.
The Versa Module Europa (VME) bus is a parallel computer bus designed to meet the requirements of space applications, high reliability, modularity and high performance. The VME64x extends the standard VME32/64 bus capabilities to provide a high-performance, cost-effective solution for a wider range of applications.
The VME (VersaModule Eurocard) bus is a general-purpose computer bus that combines the electrical standard of Motorola’s Versa bus with the mechanical form factor of the Eurocard standard established in Europe, an open architecture.
It defines a system for interconnecting data processing, data storage, and peripheral control devices in a closely coupled hardware architecture. After years of transformation and upgrading, the VME system has developed very well, and the products developed around it have covered the fields of industrial control, military systems, aerospace, transportation and medical treatment.

VME7740-841
