140CPU65260 共有4个通信端口

特征

140CPU65260共有4个通信端口。一个Modbus (RS-232/RS-485)、一个Modbus Plus (RS-485)、一个USB和一个以太网。CPU模块需要2760 mA的总线电流。该模块还带有一个钥匙开关。它的离散(位)参考容量是62千字节，寄存器(字)参考容量也是64千字节。它的电池保质期为10年，使用寿命为12 mAh。140CPU65260使用3V锂电池。

CPU模块包含许多内置诊断功能。通电后，它将检查和诊断RAM、RAM地址、执行校验和、用户逻辑和处理器的任何问题。运行时，它将检查除处理器之外的所有功能。

优势

140CPU65260固件历史悠久。发布版本是Unity Pro V2.0。随着时间的推移，对各种固件版本进行了50多次更改，纠正了许多错误和问题。您应该始终将您的模块更新到最新的固件版本。高于3.30版的固件版本必须与5.8版的Copro一起使用。

如何使用140CPU65260

140CPU65260固件版本V3.5和所有以前的版本都包含产生多个漏洞的硬编码后门，允许黑客(甚至远程黑客)查看固件、修改模块的网站、修改密码以及下载和运行自定义固件。

140CPU65260

trait

140CPU65260 A total of four communication ports. One Modbus (RS-232/RS-485), one Modbus Plus (RS-485), one USB, and one Ethernet. The CPU module requires 2760 mA of bus current. The module also has a key switch. It has a discrete (bit) reference capacity of 62 kilobytes and a register (word) reference capacity of 64 kilobytes. It has a battery life of 10 years and a service life of 12 mAh. 140CPU65260 Uses a 3V lithium battery.

The CPU module contains many built-in diagnostic functions. When powered on, it checks and diagnoses any problems with RAM, RAM addresses, execution checksums, user logic, and the processor. At runtime, it checks everything except the processor.

advantage

The 140CPU65260 firmware has a long history. The release is Unity Pro V2.0. Over 50 changes were made to various firmware versions over time, correcting many errors and issues. You should always update your modules to the latest firmware version. Firmware versions higher than version 3.30 must be used with version 5.8 of Copro.

How to use 140CPU65260

140CPU65260 firmware version V3.5 and all previous versions contain hard-coded backdoors that create multiple vulnerabilities, allowing hackers (even remote hackers) to view the firmware, modify the module’s website, change passwords, and download and run custom firmware.

140CPU65260
