133323-01 Bentley 通讯网关监测 具有广泛的通讯能力

品牌 bently
型号 3500/92
品名 通讯网关监测
bently3500/92/90通讯网关监测具有广泛的通讯能力，可通过以太网TCP/IP 和串行(RS232/RS422/RS485)通讯协议将所有框架的监测数据和状态与过程控制和其它自动化系统集成。它也支持与3500 框架组态软件和数据采集软件的以太网通讯。支持的协议包括：
1、Modicon Modbus?(通过串行通讯)
2、 Modbus/TCP(用于TCP/IP 以太网通讯的串行Modbus 的另一种形式)
3、有的本特利内华达协议(与3500 框架组态和数据采集软件包通讯)
3500/92 通过RJ45 与10BASE-T 星型拓扑以太网络连接。
3500/92 具有与3500/90 相同的通讯接口、通讯协议以及其它特点，不同的是，3500/92 具有可
组态的Modbus 寄存器功能，能提供与初始值寄存器一样的功能。
前面板发光二极管（LED）状态
OK LED: 指示3500/92 运行正常。
TX/RX LED: 指示3500/92 与3500 框架中的其它模块通讯。

本特利bently3500/92/90通讯网关监测系列产品之外，3500/33 16通道继电器模块，3500/46M水电监测器、3500/60和3500/61温度监测器、3500/62过程变量监测器、3500/72M活塞杆位置监测器、3500/77汽缸压力监测器、3500/93 LCD显示装置和3500/95系统集成pc显示装置等产品，相对来说，不是经常用，有需要的客户可以详情咨询~~
bently3500系列支撑运作的就是3500系统软件在3500 机械保护系统中共有如下三个软件包：
1. 框架组态软件 – 用于组态所有的3500 模块。
2. 数据采集/DDE （动态数据交换）服务器软件：用于采集和保存来自3500 系统的静态数据。DDE 服务器具有数据输出功能，用于与第三方软件集成，如工厂历史数据、过程控制系统以及人机接口等。
3. 操作者显示软件 – 用于显示3500 数据采集软件采集的信息。

133323-01

Brand bently
Model 3500/92
Product name communication gateway monitoring
bently3500/92/90 Communication Gateway Monitoring has a wide range of communication capabilities to integrate all framework monitoring data and status with process control and other automation systems via Ethernet TCP/IP and serial (RS232/RS422/RS485) communication protocols. It also supports Ethernet communication with the 3500 framework configuration software and data acquisition software. Supported protocols include:
1. Modicon Modbus? (via serial communication)
2, Modbus/TCP(another form of serial Modbus for TCP/IP Ethernet communication)
3, some Bentley Nevada protocol (with 3500 framework configuration and data acquisition package communication)
The 3500/92 is connected to the 10BASE-T star topology Ethernet network by RJ45.
The 3500/92 has the same communication interface, communication protocol, and other features as the 3500/90, except that the 3500/92 has the ability to
The Modbus register function of the configuration can provide the same function as the initial value register.
Front panel light emitting Diode (LED) status
OK LED: indicates that 3500/92 is operating properly.
TX/RX LED: Indicates that the 3500/92 communicates with other modules in the 3500 frame.

Bentley Bentley 3500/92/90 communication gateway monitoring series products, 3500/33 16-channel relay module, 3500/46M hydropower monitor, 3500/60 and 3500/61 temperature monitor, 3500/62 process variable monitor, 3500/72M piston rod position monitor, 3500/77 cylinder pressure monitor, 3500/93 LCD display device and 3500/95 System integrated pc display device, etc. Relatively speaking, it is not often used, and customers in need can consult for details ~~
The bently3500 series supports the operation of the 3500 System software. The following three software packages are available in the 3500 Mechanical Protection system:
1. Framework configuration software – used to configure all 3500 modules.
2. Data Acquisition /DDE (Dynamic Data Exchange) server software: used to collect and save static data from the 3500 system. DDE servers have data output capabilities for integration with third-party software, such as plant history data, process control systems, and human-machine interfaces.
3. Operator Display software – used to display information collected by 3500 data acquisition software.
